CBMM Ship Plans by Crockett Brothers Inc Boatyard (Builder)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1993.0067.0191.0018' Sailing SkiffSkiffBrownlee, Edward G - Creator; Crockett Brothers Inc Boatyard, - Builder1938Plans for an 18' Sailing Skiff built in 1938 at Crockett's Yard in Oxford MD. The boat was owned in 1945 by Wm. L. Benson of Oxford MD. Lines/dimensions taken off in September 1945. Drawn by Edward G. Brownlee on July 8, 1946. Boat length overall is 18' 8". Drawings depict the sail plan, hull lines, and construction plan. A note on the reverse side states it belongs to C. Lowndes Johnson. Scale: 1" = 1'. Material is blueprint.29.000in - 34.000inCrockett's Yard - Oxford - MDImage 1open CBMM page
