CBMM Ship Plans by Deschamps, Edme-Hilaire (Creator)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
2010.0004.0001.00Centerboard Oyster Sloop Masonic GuideSloopDeschamps, Edme-Hilaire - CreatorExact 08/30/1934 - 08/30/1934Plans for the Centerboard Oyster Sloop Masonic Guide, built in 1850 at Sands Point MD. Drawings depict the outboard profile with sail plan. Material is heavy paper21.250in - 20.500in- Sands Point - MDImage 1open CBMM page
2010.0004.0002.00Centerboard Oyster Sloop Masonic GuideSloopDeschamps, Edme-Hilaire - CreatorExact 09/30/1934 -Plans for the Centerboard Oyster Sloop Masonic Guide, built in 1850 at Sands Point MD. Drawing depicts the outboard profile with sail plan. It is a copy of 2010.0004.0001.00. Material is photocopy.21.250in - 20.500in- Sands Point - MDImage 1open CBMM page
