CBMM Ship Plans by Hartge, Ernest H (Designer)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1977.0018.0002.01Chesapeake 20 class sloopSloopHartge, Ernest H - DesignerChesapeake 20 class sloop. By designer E.H. Hartge. Plans A-E form 1 set.Image 1
Image 2
Image 3
Image 4
Image 5		open CBMM page
1997.0051.0001.0120' Knockabout Albatross ClassNot specifiedHartge, Ernest H - Designer; Hartge, Ernest H - BuilderThree sheets of drawings of a 20' Knockabout Albatross Class. Designed & built by Ernest Hartge. Consists of one set of Plans A-C. Plan A is an outboard profile. Plan B depicts the lines. Plan C is the construction plan.24.000in - 36.000inImage 1
Image 2
Image 3
Image 4
Image 5		open CBMM page
