CBMM Ship Plans by Johnson, George A. (Builder)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1993.0001.0107.01Ships plans for bugeye "BROWN SMITH JONES". A) LiBugeyeBrownlee, Edward G - Designer; Johnson, George A. - BuilderExact 01/01/1940 -Ships plans for bugeye "BROWN SMITH JONES". Built in 1894 for the Maryland Oyster Navy/Oyster Fishery Police. It was subsequently converted to a yacht. The vessel had a tender named Tom Dick Harry. In 1958, the vessel sank at Woods Hole and was later raised. A) Lines & deck plan B) Profile, sail and rigging plan. Boat size: 65' 6". Condition: Poor. Material: Pencil on paper.- Cambridge - MDImage 1
Image 2
Image 3
Image 4		open CBMM page
