CBMM Ship Plans by Johnson, James G (Creator)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1993.0067.0201.0017' V-Bottomed Cat BoatCatboatJohnson, James G - CreatorExact 03/01/1924 -Plans for a 17' V-Bottomed Cat Boat built in 1924 for the Tilghmans of Gross Coate. Drawn by J.G. Johnson. Drawing depicts the hull lines. Material is pencil on paper.17.000in - 23.000inImage 1open CBMM page
1993.0067.0202.00Yawl Vingt TroisYawlJohnson, James G - CreatorPlans for the Yawl Vingt Trois drawn by J.G. Johnson. Drawing depicts the sail plan (see also 1993.0067.0198.00 for related drawing). Scale is 3/8" = 1'. Material is pencil on paper.20.500in - 18.500inImage 1
Image 2		open CBMM page
1993.0067.0203.01Yawl Rigging for the AnnaYawlJohnson, James G - CreatorCirca 01/01/1904 -Plans for the Yawl Rigging for the Anna drawn by J.G. Johnson. One set of Plans A-B. Plan A is the sail plan and outboard profile depicting a yawl rig. Plan B is a midship section for the Anna and a cross section of an unidentified vessel. On the reverse side are various calculations. Scale for Plan A is no scale; Plan B is 1" = 1'. Material for Plans A and B is pencil on paper, drawn on the reverse of an envelop.19.000in - 18.500inImage 1
Image 2		open CBMM page
