CBMM Ship Plans by Jones, Paul (Builder)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
2024.0026.0002Deadrise SandraWorkboatMoale, H. Richard - Artist; Jones, Paul - Buildercirca 1970sPlans for the Deadrise Sandra, built in 1950 by Paul Jones. Boat was owned by Donald Gower of Tilghman, MD. Vessel dimensions are 39' length overall, 9.3' beam, 3.2' draft, and 7 tons displacement. The vessel is a gas powered deadrise, cross-planked workboat used for diving for oysters. Three drawings depict the outboard profile, an incomplete plan view, and detail of framing at transom at frame 1. Plan is stored on a roll tube. Scale is 1" = 1'. Material is ink on linen.[H]42.5in - [W]55.5in- Crocheron - MARYLANDImage 1open CBMM page
2024.0026.0003Deadrise SandraWorkboatMoale, H. Richard - Artist; Jones, Paul - Buildercirca 1970sPlans for the Deadrise Sandra, built in 1950 by Paul Jones. Boat was owned by Donald Gower of Tilghman, MD. Vessel dimensions are 39' length overall, 9.3' beam, 3.2' draft, and 7 tons displacement. The vessel is a gas powered deadrise, cross-planked workboat used for diving for oysters. Twelve drawings depict the outboard profile, a deck plan, sections at the bow, midships, and stern, a detail of the framing at the transom at frame 1, a detail of the stern post steering assembly, a detail of how the deck is fastened to a knee, and three sections at frames 8, 17, and 20, and a sketch of the planking layout. A note states that the planking is fore and aft up to rear of the cabin and perpendicular to the keel. Another note states that frame 1 is 9.25" from bottom, 11.5" top from inside transom, and transom joined by planks on outside. Plan is stored on a roll tube. Scale is 3/8" = 1'. Material is pencil on graph paper and yellow loose leaf paper taped to the top right corner of the graph paper.[H]23.5in - [W]25.25in- Crocheron - MARYLANDImage 1open CBMM page
2024.0026.0004Deadrise SandraWorkboatMoale, H. Richard - Artist; Jones, Paul - Buildercirca 1970sPlans for the Deadrise Sandra, built in 1950 by Paul Jones. Boat was owned by Donald Gower of Tilghman, MD. Vessel dimensions are 39' length overall, 9.3' beam, 3.2' draft, and 7 tons displacement. The vessel is a gas powered deadrise, cross-planked workboat used for diving for oysters. Two drawings depict the outboard profile at the waterline with a partial drawing of the outboard profile underwater and a partial of the deck plan. Plan is stored on a roll tube. Scale is 1" = 1'. Material is pencil on graph paper.[H]22in - [W]47in- Crocheron - MARYLANDImage 1open CBMM page
2024.0026.0005Deadrise SandraWorkboatMoale, H. Richard - Artist; Jones, Paul - Buildercirca 1970sPlans for the Deadrise Sandra, built in 1950 by Paul Jones. Boat was owned by Donald Gower of Tilghman, MD. Vessel dimensions are 39' length overall, 9.3' beam, 3.2' draft, and 7 tons displacement. The vessel is a gas powered deadrise, cross-planked workboat used for diving for oysters. Eight drawings depict the outboard profile at the waterline, a deck plan, a section of the windshield for the cabin, detail of the framing for the transom at frame 1, the forward hand rail, the low section (trunk) of the cabin, a partial section midships, and the transom with the vessel name (Sandra) and home port (Tilghman MD). No scale defined, but specific measurements are identified throughout the drawings. Plan is stored on a roll tube. Material is pencil on graph paper/mylar.[H]10.5in - [W]15.5in- Crocheron - MARYLANDImage 1open CBMM page
2024.0026.0006Deadrise SandraWorkboatMoale, H. Richard - Artist; Jones, Paul - Buildercirca 1970sPlans for the Deadrise Sandra, built in 1950 by Paul Jones. Boat was owned by Donald Gower of Tilghman, MD. Vessel dimensions are 39' length overall, 9.3' beam, 3.2' draft, and 7 tons displacement. The vessel is a gas powered deadrise, cross-planked workboat used for diving for oysters. Sheet consists of numerouse sketches and notes. Ten sketches depict one of the knees/clamps, keel, transom detail at frame 1, rudder post at stern, plan view of the steering mechanism, detail of the gas tank and the fuel line going to the engine, plan view of the bow, inboard profile of the bow and front of the cabin, detail of the base of the windows in the pilot house, and a detail of the propellor shaft where it penetrates the hull. The sheet includes a list of five items/tasks for the hull, to include measuring the ribs, counting the ribs, identifying the direction of the planking, sketching the cabin interior, and measuring supports for cockpit deck. Plan is stored on a roll tube. Material is pen and pencil on yellow lined legal paper.[H]12.5in - [W]8in- Crocheron - MARYLANDImage 1
Image 2		open CBMM page
