Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
2004.0028.0234.00Pipe BoxUnidentified vesselLiener, Josef W - Designer12/3/1981Plan for a Pipe Box for unidentified vessel. Drawing #269. Drawn by Joe W. Liener. Two drawings depict profile views of the pipe box and associated drawer. Pipe box is made of 3/16" pine. Material is pencil on paper.[H]22" - [W]6.75"Image 1
Image 2		open CBMM page
1994.0027.0023.00Pungy Thomas E. BellPungy schoonerLiener, Josef W - DesignerExact 06/07/0088 -Plans for Pungy Thomas E. Bell. Depicts hull lines only from Kirby's half model. Drawn by Joe Liener. No lateral plane structure and no reg shown. Boat dimensions are length overall 60' 5" and beam 9' 2". Pencil on drafting paper.open CBMM page
1994.0027.0057.0022' Sharptown ShadbargSkiffLiener, Josef W - DesignerExact 01/01/1984 -Plan for a Sharptown Shadbarge. Flat bottom, transom, stern, narrow beam sailing skiff. Drawing by Joe W. Liener. Boat length overall is 22'. Iink on posterboard.open CBMM page
1994.0027.0059.0016' Skiff (two sail bateau)SkiffLiener, Josef W - DesignerExact 01/01/1979 -Plan for a skiff (two sail bateau) by J.W. Liener in 1979. Drawings depict hull lines, offsets, construction plan, sail plan, and notes. Boat length overall is 16' 8". Blueline print.open CBMM page
1994.0027.0079.00Chesapeake Skipjack RelianceSkipjackLiener, Josef W - DesignerPlan for the Chesapeake Skipjack Reliance. Depicts the lines. Copy 1 is pencil on drafting paper. Copy 2 is a blueline print.open CBMM page
1993.0010.0001.0013' Yawl Boat for the Skipjack E.C. CollierSkipjackLiener, Josef W - DesignerExact 01/01/1993 -Plans for a 13' Yawl Boat for the Skipjack E.C. Collier drawn by Josef Liener on 9/14/1978, copyright not transferred. Drawings depict the side expansion from a previous yawl boat, inboard profile, half-breadth with deck plan, cross section at frame 5, and table of offsets. Scale is 2"=1'. Material is xerox on mylar.23.750in - 36.125inopen CBMM page
1993.0038.0001.00Push BoatBoatLiener, Josef W - Designer; Harrison, John B - Builder11/21/1979Plans for a Push Boat. Lines were taken from a model of the push boat made by John B. Harrison, Tilghman Island MD for John Wilson, Tilghman Island MD. Model owned by Stanley Covington, Tilghman Island MD. Copyright did not transfer. Drawings depict the sheer, half-breadth and body plan with table of offsets. Scale is 1"=1'. Drawing was copied on 3/12/1993.[H]16in - [W]24in- Tilghman - MDImage 1
Image 2		open CBMM page
1994.0027.0060.0016' Skiff (two sail bateau)SkiffLiener, Josef W - DesignerExact 01/01/1979 -Plan for a skiff (two sail bateau) by J.W. Liener in 1979. Drawings depict hull lines, offsets, construction plan, sail plan, and notes. Boat length overall is 16' 8". Blueline print.open CBMM page
2004.0028.0088.0125' Hooper IslanderDraketailLiener, Josef W - DesignerPlans for a 25' Hooper Islander, Design #181, drawn by Joe Liener. The stern is a draketail/torpedo boat style. One set of Plans A-B. Plan A depicts preliminary drawings and the table of offsets. Plan B is the body, sheer, and half-breadth lines and table of offsets. Joe Liener's initials are in the lower right. Material is Gentry-Morrison Funeral Home paper.16.625in - 21.875inImage 1
Image 2		open CBMM page
2004.0028.0088.0225' Hooper IslanderDraketailLiener, Josef W - DesignerExact 04/27/1977 -Plans for 25' Hooper Islander, Design #181. Stern is a draketail/torpedo boat style. Drawing depicts the body, sheer, and half-breadth lines and a table of offsets. Material is graphite on tracing paper. Joe Liener's initials are in the lower right corner.22.750in - 36.250inImage 1
Image 2		open CBMM page
2004.0028.0171.00Workboat MarionWorkboatLiener, Josef W - DesignerExact 05/25/1982 -Plans for the Workboat Marion, Design #273. Drawing depicts the body, sheer and half breadth plans. Name and measurements in upper right corner, signed and dated in lower right corner. Material is graphite on paper.11.000in - 21.500inImage 1
Image 2		open CBMM page
