CBMM Ship Plans by Marsh, Leon and Gradon (Creator)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1998.0012.0001.0128' Crab scrape Jessica LynnNot specifiedMarsh, Leon and Gradon - Creator; Gregory, Joseph - DesignerExact 06/01/1998 -Construction plan for 28' crab scrape Jessica Lynn. Deadrise open hull with gasoline engine; scale: 3/4" =1'-0". Plan A is sepia. Plan B is blueprint.32.500in - 23.500inImage 1
Image 2		open CBMM page
