CBMM Ship Plans by Munroe, Wirth M (Designer)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1993.0067.0208.00Chesapeake Bay Auxiliary KetchKetchMunroe, Wirth M - DesignerExact 11/09/1962 -Proposed plans for a Chesapeake Bay Auxiliary Ketch designed by Wirth M. Munroe for Slad Dale. Drawing No. 62-101-B. Drawings depict the sail plan, particulars, and sections. Scale is .5" = 1'. Material is blue line print with blue ink alterations.32.500in - 23.000inImage 1open CBMM page
