CBMM Ship Plans by Pusey & Jones Corp. (Designer)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1994.0027.0088.00Passenger and cargo boatBoatPusey & Jones Corp., - DesignerPassenger and cargo boat, proposed design. General arrangement drawing by Pussey and Jones Corp. Wilmington, DE. LOA 138'7" LWL 125', Beam 26' Depth 12'6"Image 1
Image 2		open CBMM page
1976.0025.0007.00Passenger and Cargo SteamerSteamerPusey & Jones Corp., - DesignerPlans for a proposed Passenger and Cargo Steamer for the Mobjack Bay run, designed by Pusey and Jones of Wilmington DE. Overall ship length is 133'. Drawings depict the outboard profile with main and upper deck arrangement plans including separate heads for blacks and whites. Material is blueprint.27.000in - 65.000in- Wilmington - DEImage 1open CBMM page
