CBMM Ship Plans by Wiley, Ralph H (Designer)

These ship plans are found in the collection of the Chesapeake Bay Maritime Museum in St. Michaels, Maryland.

More information about how to obtain copies of the plans, or how to visit the CBMM archives to examine these and other plans, may be found at the "open CBMM page" link.

Catalog #TitleBoat TypeArtist/MakerDate MadeDescriptionDimensionsPlace MadeFull ImageCBMM Cat. Page
1981.0032.0012.01Schooner WavePungy schoonerJohnson, C. Lowndes - Designer; Wiley, Ralph H - DesignerRange, Cir 01/01/1937 - 12/31/1940Plans for the Schooner Wave, a Chesapeake Bay Pungy. One set of Plans A-C. Plan A is the sheer, half-breadth and body plan from C. Lowndes Johnson blueprint of Pungy Wave. Plan B is a preliminary sketch of the interior layout for the schooner Wave, as modified by Wiley. Plan C is the finished sketch of the interior layout for the schooner Wave, as modified by Wiley. Material is blueprint for Plan A; pencil on tracing paper for Plans B-C.open CBMM page
1981.0032.0015.00Tancook Whaler Mocking BirdCutterWiley, Ralph H - Designer; Wiley, Ralph H - BuilderCirca 01/01/1938 -Plans for the Tancook Whaler Mocking Bird. Built in 1940. Vessel dimensions are overall length 31' 6", 8' beam, 4' 6" draft. The vessel was rigged as a cutter. Drawing depicts the inboard profile, deck plan, and cross sections at stations 4 and 6. Material is photostat.- Oxford - MDopen CBMM page
1981.0032.0018.01Tancook Whalers Fox and VixenCutterWiley, Ralph H - Designer; Wiley, Ralph H - BuilderCirca 01/01/1946 -Plans for the Whaler Cutter Fox and Vixen. Boat dimensions are 37' 6" x 28' 4" x 8' 6" x 4' 8". The vessels used a cutter rig. One set of Plans A-B. Plan A is the hull profile, cabin layout, accomodation plan, and cross-section at midships. Plan B is the sheer, half-breadth and body plan with a partial table of offsets. Material is ink on tracing paper.- Oxford - MDImage 1
Image 2
Image 3
Image 4
Image 5
Image 6
Image 7
Image 8		open CBMM page
1981.0032.0036.01V-Bottom Tow BoatBoatWiley, Ralph H - DesignerCirca 01/01/1929 -Plans for a V-Bottom Tow Boat. Vessel dimensions are 50' x 14' x 3'. One set of Plans A-C. Plan A is the sheer, half-breadth and body plan with table of offsets and bottom planking plan. Drawing #50-C-101. Plan B is the outboard profile and interior arrangement plan for engineering spaces. Drawing #50-C-102. Plan C is the construction details with cross section at station 9. Drawing #50-C-103. Material is ink on linen.open CBMM page
